- Ball Bearings
- Continuous Duty
- Internal junction box
- Keyed and Stainless Steel Threaded Shafts
- NEMA 56C Mount
- Open Dripproof
- 40C Ambient
- 60 Hertz
Running on a continuous current, the NEMA C-Face 3-Phase Pump Motor provide excellent performance. Available in 1/2″P to 2HP, the NEMA C-Face 3-Phase Pump Motor is ideal for moving water efficiently. Its body is made with keyed or threaded stainless steel shafts and its mounting bracket and end frames are constructed from die-cast corrosion resistant aluminum. The NEMA C-Face 3-Phase Pump Motor contains a 1/2″ x 14? thread tapped opening for convenient conduit fitting. Supplied with a horizontal canopy, the NEMA C-Face 3-Phase Pump Motor can be altered to suit vertical operation for versatility.
| Voltage: | 230V / 460V |
| Phase Type: | Three Phase |
| Flange Type: | C Flange |
| Speed Settings: | Single Speed |
| Flange Type: | J Flange |
| Installation Type: | Residential |
| Shaft Type: | Threaded |
| Pool Type: | Spa/Hot Tub |
| Voltage: | 208 – 230V / 460V |
| Horsepower: | 1 HP |
| Service Factor: | 1.25 – 1.50 |
| Product Type: | Pool Motor |
| Energy Efficiency: | Standard |
| Motor Frame: | 56 Frame |
| Manufacturer: | Century A.O. Smith |
| Warranty: | 1-Year |
